Quad Bags (Multi-Purpose Lift Bags) |
|
Designed as a multi-purpose bag that can be used as a lift bag,
an upline float, drybag, or an inflatable dive flag/float.
SUBSALVE USA Quad Bags are manufactured of high-strength,
lightweight, vinyl-coated nylon fabric and roll up small enough
to carry on every dive. They are screened on both sides with a
bright red "divers down" flag for high visibility, and are
equipped with an oral inflator and an optional lanyard-operated
dump valve. |
A must for tech
divers, wreck divers, beach and boat divers. |
All SUBSALVE USA Quad Bags are equipped with: |
Quad bags available in four sizes: 50
lb., 100 lb., 200 lb. |
|
|
|
|
|
Commercial Bags (Open Bottom) |
|
Commercial Lift Bags are especially suited for remote locations
or for deployment from small craft.
SUBSALVE USA Commercial Lift Bags are capable of being
used by a single diver. These heavy-duty lift bags are ideal for
use in light salvage, object recovery, construction, and
scientific applications. |
Manufactured from heavy-duty nylon
fabric coated with urethane for: |
-
High strength
-
Very resistant to abrasion
-
Not affected by most
petro-chemicals
-
UV resistant
-
The Commercial Lift Bags have
6000 lb. rated strength, resin-treated nylon lift straps
sewn directly to the bottom of the lift bag, and has a safe
working ratio of 6:1.
|
All SUBSALVE USA
Commercial Lift Bags are equipped with: |
-
Subsalve
Plunger Dump Valve (which provides air control with a
push-button knob at the top of the bag and a lanyard at the
bottom of the bag)
-
1/4" NPT inflation port (for
remote filling or multiple bag manifolding or to install our
optional brass quick disconnect)
Commercial Lift
Bags available in three sizes: 100 lb., 200 lb., 500 lb. |
Special Order. Please allow additional lead time. |
|
|
|
|
|
BRS-100 Bomb Recovery System
|
The BRS-100 Bomb Recovery
System is specially designed for use by law enforcement to
recover or remove explosives or other dangerous devices. |
|
The BRS-100 System features include: |
-
One 25lb float
-
One 50b float
-
One 100lb float Each float includes one
2.5psi pressure relief valve and a 1/4in quick disconnect
for inflation.
-
100ft LP inflation hose with quick
disconnects
-
105ft high strength polypro line with
carabiner
-
Carry bag
|
Special Order. Please allow
additional lead time. Item is Oversized. Shipper's Surcharge:
$50.00 ea. Surcharges will not display in the Shopping Cart, but will
be added at the time your order ships.
|
Price:
$1035.00
|
|
|
VRS2000 Vehicle Recovery System
|
The VRS 2000 is the first and
only self-contained underwater vehicle recovery system available
today.
Using state-of-the-art design materials and manufacturing
processes, this all-purpose system is designed to be portable
for rapid deployment, and is the result of an 18-year
evolutionary process drawing from hundreds of product
applications, combined with technological advancements.
SUBSALVE USA engineers and technicians have worked with the
commercial and public safety diving communities to develop and
refine this system, not just on the drawing board, but in the
water on recoveries. |
With the lift rings
spaced at 40" apart and the carabiner on the end of the chain,
attachment to the front and rear bumper or shock brackets of
most vehicles is quick and easy.
This design also enable the
bags to be rigged to cradle the car by connecting the two 3'
chains together to pass under the vehicle. The lift bags are
equipped with a pressure relief valve in each corner to prevent
blow-up and also to allow the diver to manually vent the bag
from any corner. A 3/4" brass ball valve is located at the top
center of each lift bag to allow for rapid deflation. |
The VRS 2000 System features include: |
-
2-2000 lb. enclosed flotation bags equipped
with a pocket to contain an 80 cu. ft. aluminum scuba
cylinder.
-
The lift bags are manufactured from a
high-strength, urethane-coated, nylon fabric which is highly
abrasion, oil, and UV resistant.
-
The air cylinder is connected to the lift bag
with a scuba yoke and hose assembly with a one-way check
valve to allow for easy tank changes while preventing any
loss of air from the bag.
-
The attachment design includes 2 stainless
steel lift rings on the top and 2 on the bottom of the bag,
allowing the lift bag to be rigged either flat or upright.
-
The bottom lift rings are each equipped with
a 3' length of 1/4" galvanized proof coil chain with a
stainless steel snap carabiner on the end.
|
VRS 2000 ( US Patent No. 5,755,172)-
Vehicle Recover System (includes 2-2000 lb. enclosed
flotation bags). |
-
Each lift bag assembly is stored and folds
back into a heavy-duty, zippered carrying case with nylon
handles and an adjustable shoulder strap.
-
The VRS 2000 System comes complete with all
of the components packed into two carrying cases, each of
which measures 51 " long by 20" high by 10" wide and weighs
approximately 65 lbs.
|
Special Order. Please allow
additional lead time. Item is Oversized. Shipper's Surcharge:
$50.00 ea. Surcharges will not display in the Shopping Cart, but will
be added at the time your order ships.
|
|
|
|
|
|
